P3.9 Indoor Holographic Transparent LED Display SMD1415 70% High Transparency
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P3.9 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case, flight case |
| Delivery Time: | 5-10 days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 3000sqm/month |
|
Detail Information |
|||
| Product Name: | P3.9 Indoor Holographic Transparent LED Display SMD1415 70% High Transparency | Brightness: | 1000-5000nits |
|---|---|---|---|
| Waterproof: | IP42 | Led Type: | SMD1415 1R1PG1PB UV |
| Driving Method: | Static | Transparent Rate: | 70% |
| Maintenance: | Rear Service | Cabinet Size: | 600/1200/1800x500/600/700/800mm |
| Cabinet Material: | Aluminum+PCB | Panel Weight: | 6 Kg/sqm |
| Highlight: | Indoor Holographic Transparent LED Display,SMD1415 Holographic Transparent LED Display,P3.9 Indoor Transparent LED Display |
||
Product Description
P3.9 Indoor Holographic Transparent LED Display SMD1415 70% High Transparency
Product Description:
P3.9 Indoor Holographic Transparent LED Display is an innovative display solution designed for indoor applications that require a high level of visual engagement without compromising on aesthetics or space. This lightweight display system, weighing only 6kg per square meter, offers a perfect blend of technology and design.
Features:
-
Transparent:Industry premiere,with no structural backbone；Real fully transparent；Permeability can reach 70%
- Thin:Module thickness<3mm；Seamless curved surface mountingIntegrated seamlessly onto glass
- Foldable and arbitrarytransformation shape；Soft and bendable.lt can becustomized into different shapes according to different scenes, for example,triangles, ellipses, etc.
- Arbitrary cutting,seamless spiced display:The screen size can be arbitrarily cropped, the closer the distance betweenthe screen beads of the seamless splicing screen, the clearer the pixeldensity. And the seamless cropped screen is more flexible to match theinstallation and regional carrier.
Technical Parameters:
| Pixel Pitch (H/V) | W:3.9;H:3.9mm | W:6.25;H:6.25mm |
| LED Configuration | SMD1415 1R1PG1PB UV | SMD1415 1R1PG1PB UV |
| Pixel Density | 65536dot/㎡ | 25600dot/㎡ |
| Transparency | <66.66% | <70% |
| Drive Scheme | 18 aisle | 18 aisle |
| Scan method | 0 Scan(6 layer PCB) | 0 Scan(4 layer PCB) |
| Refresh Rate | 1920-3840Hz | 1920-3840Hz |
| Module Size | 375/750/1125/1500X125mm(L/R) | 600/1200/1800X100mm(L/R) |
| Module Resolution | 96/192/288/384X32dot | 96/192/288X16dot |
| Product Size | 375/750/1125/1500X500mm | 600/1200/1800X500/600/700/800mm |
| Cabinet Resolution | 96/192/288/384X128dot | 96/192/288X80/96/112/128dot |
| Cabinet Weight | 6kg/㎡ | 6kg/㎡ |
| IP Rating ( front/back) | IP42 | IP42 |
| Brightness | 1000-5000nits/㎡ | 1000-5000nits/㎡ |
| Viewing Angle (H/V) | 140°/140° | 140°/140° |
| Viewing Distance | 4m | 6 m |
| Gray Scale | 16 bit | 16 bit |
| Max.Power Consumption | 800W/m² | 800W/m² |
| Ave.Power Consumption | 240W/m² | 240W/m² |
| Maintenance | Rear service | Rear service |
| Environment | indoor | indoor |
| Operation Power | AC:100_240V;50/60Hz | AC100_240V,50/60Hz |
| Operating Temperature | ﹣10℃~40℃ (work) | ﹣10℃~40℃ (work) |
| Operating Humidity | 35%～85% (work),10%～90% | 35%～85% (work),10%～90% |
| Operating Life | 100,000hours | 100,000hours |
Applications:
-
Retail Displays: Enhance product showcases with dynamic holographic displays that capture the attention of shoppers and provide an immersive shopping experience.
-
Galleries and Exhibitions: Provide a unique viewing experience for art and exhibits, allowing visitors to see the artwork in a new light.
-
Corporate Settings: Use in conference rooms and lobbies for impactful presentations and informational displays that leave a lasting impression.
-
Entertainment Venues: Create immersive environments in theaters, clubs, and other entertainment spaces, adding depth and excitement to the atmosphere.
FAQ:
Q1: Are you a trading company or manufacturer?
A1: We are an original LED display manufacturer.
Q2: Can the product be customized?
A2: Absolutely! We can tailor products to your needs. Just share specifics like dimensions, whether it's for indoor or outdoor use,installation type, minimum viewing distance, and more.
Q3: How do you ensure the quality of your LED displays?
A3: Quality is our priority. Our professional R&D and QC teams have established standardized processes to ensure product excellence. We conduct a thorough aging test and waterproof check before any product is shipped. Plus, we offer a 2-year warranty for our products.
Q4: What's the typical delivery time?
A4: Generally, after receiving an advance payment, it takes us about 10 to 15 days to deliver.
Q5: Can I have my logo printed on the LED screens?
A5: Of course! Just make sure to inform us ahead of production, and we can confirm the design based on a sample we provide.
