P0.7 COB Small Pitch LED Display 600x337.5mm Die-casting Aluminum Cabinet
Product Details:
| Place of Origin: | CN |
| Brand Name: | Visual World |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P0.7 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case, export carton box |
| Delivery Time: | 12 work days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 sqm/month |
|
Detail Information |
|||
| Product Name: | P0.7 COB Small Pitch LED Display 600x337.5mm Die-casting Aluminum Cabinet | Pixel Pitch: | P0.7/P0.9/P1.25/P1.56 |
|---|---|---|---|
| Cabinet Size: | 600x337.5mm | Maintenance: | Front Service |
| LED Type: | COB | Cabinet Weight: | 4.6kg |
| Cabinet Material: | Die-casting Aliuminum | Installation Type: | Mounting/Hanging/Stacking |
| Highlight: | 600x337.5mm Small Pitch LED Display,P0.7 COB Small Pitch LED Display |
||
Product Description
P0.7 COB Small Pitch LED Display 600x337.5mm Die-casting Aluminum Cabinet
Product Description:
P0.7 COB Small Pitch LED Display is a cutting-edge display solution designed for high-definition visual experiences in indoor environments. With a pixel pitch of 0.7mm, this display offers incredibly detailed imagery and crisp text rendering, making it ideal for applications such as command centers, high-end conference rooms, and broadcast studios.
Features:
- Full flip-chip COB process, protection technology includes: anti-collision, waterproof, moisture-proof, salt spray, (to prevent LED screens from blinding or caterpillar failures caused by lamp tubes getting damp in high-humidity and salt-spray environments).
- Supports LCD status display panel, which can intuitively understand the real-time status of the cabinet operation.
- The module PCB adopts HDI multi-layer circuit board design, with good color uniformity and uniform temperature distribution.
- The entire series adopts Sunrise's energy-saving common cathode chip, which has higher performance and a grayscale level of up to 16bit.
Technical Parameters:
| Model | P0.7 |
| Pixel Pitch | 0.7mm |
| LED Type | COB |
| Cabinet Dimension | 600*337.5*35mm |
| Module Size | 150x168.75 mm |
| Cabinet Weight | 4.6kg |
| Cabinet Material | Die-casting Aluminum |
| Driving Type: | 1/36 |
| maintenance | Front service |
| Brightness | 0-2000 nits |
| Max/Avg Power | 390/136 W/m2 |
| IP Rating |
Front: IP65 Rear: IP30 |
| Refresh Rate | >3840Hz |
| Installation Type |
Mounting Hanging Stacking |
| Gray Scale | 16bit |
| Viewing Angle | H:170°；V:170° |
| Operational Temp | -20℃~+50℃ |
| Operational Humidity | 10%-90%RH |
Applications:
- Digital Signage system
- Chain store
- Street furniture
- Billboard
- Football stadium
- Perimeter LED poster
- Arena display, etc.
FAQ:
Q1: Are you a manufacturer or a trading company?
A1: We are a professional OEM/ODM manufacturer with 10 years of professional experience in the LED display industry.
Q2: How is your factory doing in terms of quality control?
A2: Quality first. We attach great importance to quality control from beginning to end. We focus on every detail. Our factory has obtained ISO9001, ISO14001,CE, RoHS, FCC certification.
Q3: What is your minimum order quantity?
A3: We can accept any quantity. And the price for
large quantities can be negotiated.
Q4: When will you deliver?
A4: According to the size and quantity of your order, we can deliver the led module within 3-5 working days and the finished led screen within 10-12 days.
Q5: What technical support can you provide?
A5: We provide various technical training free of charge, including the operation and maintenance training of LED display in the factory. We can send a team of engineers to the customer's country to guide the installation.
Q6: How long is the warranty period?
A6: The standard warranty period is 2 year. Depending on the requirements, the time may be longer.
Q7: Do you provide free spare parts in every order?
A7: Yes, a certain number of spare parts will be provided free of charge, including modules, power lines, signal lines, LED lights, IC, masks, power supplies, receiving cards, etc.
